Product model | XR850 Practical |
Accuracy | General target 0-850m
High reflection target 0-1200m |
Accuracy | ±0.5m(<400m) |
±0.8m-1m(400m-1000m) |
±1m(>1000m) |
Inclination | Range：±90° |
Azimuth | No |
ML | Span measurement between two targets in two dimensional vertical plane |
Measure mode | VD ML(2 points measure height difference) |
HD ML(2 points in vertical measure horizontal distance/slope degree) |
HT(2 points measure height) |
HD HT(3 points measure height) |
HD/SD(1 point measures horizontal distance) |
VD(1 ponint measures vertical distance/inclination) |
Target mode | Standard close and far |
Magnification | 7X |
Optical display | LED |
Resolution of range | 10cm |
Waterproof level | IP56 |
Laser wavelengths | 905nm |
Laser level | CLASS 1 |
Battery type | CR123A 2- |
Battery use time | 16 hours |
Size | 126.5mm*108.5mm*48mm |
Weight | 400g |
Bluetooth | No |
Other configuration | Recumbent operation /built in RS232 serial port/Rxiry app |
